Spotlight on

Product highlights

We are setting the benchmark for healthy, smart and secure building with outstanding, pioneering solutions. For our AWS 75.SI+ optimized window system, this means:
1
Passive house window in the standard system
2
Very wide variety of designs
3
Schüco AvanTec SimplySmart system fittings to RC 3
image cmcid:163366

Schüco AWS optimized window system: a comprehensive, high-performance window system for sustainable buildings

The Schüco AWS 75.SI+ optimized (Super Insulated) window system for the 75 mm basic depth is part of the Schüco AWS system platform and allows high energy efficiency and architectural requirements to be fulfilled through its future-oriented, optimised U values.

The window system has been passive house-certified from a face width of 178 mm by the PHI Darmstadt.

Thanks to newly developed thermal insulation technology, our optimised systems achieve a high level of energy efficiency. This significantly improves the thermal performance values compared to the AWS standard system.

AWS 75.SI+optimized is a comprehensive and high-performance vent and frame system with numerous solutions.

Awards & Certifications

award cmcid:151550

Awards & Certifications

award cmcid:182871

Fabrication benefits

  • More applications thanks to improved U values and passive house certification through new, optimised insulating bars, a thermally insulated centre gasket and optimised glazing rebate insulation.
  • Schüco AvanTec SimplySmart fitting ensures efficient fabrication: flexible, simple and intuitive
  • Vent parts are self-positioning and installed without tools
  • Fittings installation without locking bar recess on the vent facilitates faster fabrication as well as simplified, efficient locking bar preparation
  • Symmetrical cavity-fitted gearbox can be used on the right and left-hand side; simplified cutting of the locking bar and reduced storage requirements
  • Rebate gasket optimised for fabrication with optional corner piece
  • .

Gallery

Technical information

Documentation

Specification texts

Test documents

Brochures
