Double-headed mitre saws

PDG Dual Cut 610 / 630 / 650

PDG Dual Cut 610 / 630 / 650

Double-headed mitre saw with jack rafter cutting and 600 mm saw blades which come from below. For aluminium profiles, can be operated directly from SchüCal.

  • Servo motor for angle setting
  • Swivel and incline feature


Technical data:

PDG Dual Cut 610

PDG Dual Cut 630

PDG Dual Cut 650

Number of CNC-controlled axes:

1

3

5

Mobile head (X axis):

CNC

CNC

CNC

Swivel:

Manual

CNC

CNC

Incline:

Pneumatic

Pneumatic

CNC

Intermediate angles for swivel feature:

Yes

Yes

Yes

Intermediate angles for incline feature:

No

No

Yes

Model:

5.0 m or 6.6 m

5.0 m or 6.6 m

5.0 m or 6.6 m

Motor:

230/400 V / 2 x 3.7 kW

230/400 V / 2 x 3.7 kW

230/400 V / 2 x 3.7 kW

Saw blade speed:

2400 rpm

2400 rpm

2400 rpm

Swivel range:

140° (outwards); 22.5° (inwards)

140° (outwards); 22.5° (inwards)

140° (outwards); 22.5° (inwards)

Angle of incline:

90° and 45° (inwards)

90° and 45° (inwards)

90° and 45° (inwards)

Saw blade diameter:

2 x 600 mm

2 x 600 mm

2 x 600 mm

Cutting length (min.):

470 mm (at 90°)

470 mm (at 90°)

470 mm (at 90°)

Cutting length (max.):

5000 mm / 6600 mm (depending on model)

5000 mm / 6600 mm (depending on model)

5000 mm / 6600 mm (depending on model)

Weight:

3150 kg / 3370 kg (depending on model)

3150 kg / 3370 kg (depending on model)

3150 kg / 3370 kg (depending on model)

PDG E-Cut 650 / 600 L / 500

PDG E-Cut 650 / 600 L / 500

Double-headed mitre saw with 650 / 600 / 500 mm saw blade. For aluminium profiles, can be operated directly from SchüCal.

  • Servo motor for angle setting


Technical data:

PDG E-Cut 650

PDG E-Cut 600

PDG E-Cut 500

Model:

5.0 m or 6.6 m

5.0 m or 6.6 m

5.0 m or 6.6 m

Motor:

230/400 V / 2 x 5.5 kW

230/400 V / 2 x 2.2 kW

230/400 V / 2 x 2.2 kW

Saw blade speed:

2800 rpm

2800 rpm

2800 rpm

Angle of incline:

20° (outwards); 45° (inwards)

20° (outwards); 45° (inwards)

10° (outwards); 45° (inwards)

Saw blade diameter:

2 x 650 mm

2 x 600 mm

2 x 500 mm

Cutting length (min.):

350 mm (at 2 x 90°); 352 mm (at 2 x 45°); 270 mm (with software)

350 mm; 270 mm (with software)

350 mm; 270 mm (with software)

Cutting length (max.):

5000 mm / 6600 mm (depending on model)

5000 mm / 6600 mm (depending on model)

5000 mm / 6600 mm (depending on model)

Weight:

2580 kg / 2720 kg (depending on model)

2000 kg / 2280 kg (depending on model)

2000 kg / 2280 kg (depending on model)

PDG Cut 550

PDG Cut 550

Double-headed mitre saw with 550 mm saw blade. For aluminium profiles, can be operated directly from SchüCal.

  • Pneumatic angle setting


Technical data:

Model:

5.5 m or 6.6 m

Motor:

230/400 V / 2 x 2.2 kW

Saw blade speed:

2800 rpm

Angle of incline:

Outwards up to 22.5°

Fixed stops at:

90°/45°/22.5° (intermediate angle can be adjusted)

Saw blade diameter:

2 x 550 mm

Cutting length (min.):

Less than 370 mm (with software)

Cutting length (max.):

5000 mm / 6600 mm (depending on model)

Weight:

1900 kg / 2400 kg (depending on model)

PDG Set

PDG Set

With 500 mm saw blade, for aluminium profiles, dimensions can be entered using keyboard.

  • Pneumatic angle setting


Technical data:

Model:

5.0 m or 6.0 m

Motor:

230/400 V / 2 x 2.2 kW

Saw blade speed:

2800 rpm

Angle of incline:

Outwards up to 22.5°

Fixed stops at:

90°/45°/22.5° (intermediate angle can be adjusted)

Saw blade diameter:

2 x 500 mm

Cutting length (min.):

300 mm, < 300 mm with short section stop

Cutting length (max.):

5000 mm / 6600 mm (depending on model)

Weight:

1830 kg / 2140 kg (depending on model)

PDG Twin

PDG Twin

With 400 mm saw blade, for aluminium profiles, dimensions can be entered using keyboard.

  • Manual angle setting


Technical data:

Model:

4.0 m or 6.0 m

Motor:

230/400 V / 2 x 2.2 kW

Saw blade speed:

2800 rpm

Angle of incline:

45° (outside) -90°

Swivel angle:

45° (outside) -45° (inside)

Saw blade diameter:

2 x 400 mm

Cutting length (min.):

421 mm; up to 210 mm with short section stop

Cutting length (max.):

4000 mm / 6600 mm

Weight:

700 kg / 867 kg (depending on the version)

Glazing bead saws

GS 500

GS 500

The GS 500 glazing bead cutting centre is used for efficient preparation of glazing beads. This means that a lot of time can be saved from measurement of the glazing beads to cutting.

  • Automatic positioning of Schüco glazing bead clips


Technical data:

Motor:

400 V

Swivel range:

+45° / 90° / -45°

Saw blade diameter:

400 mm

Cutting length (min.):

200 mm

Cutting length (max.):

6000 mm

Weight:

480 kg

GS200 / GS100

GS200 / GS100

Glazing bead saws for glazing bead preparation.

  • Automatic positioning of Schüco glazing bead clips


Technical data:

Model:

GS 200

Motor:

400 V / 2.8 kW

Swivel range:

+45° / 90° / -45°

Saw blade diameter:

400 mm

Weight:

370 kg

GS 50

GS 50

When used together with a Schüco PES 400 single-head saw (or similar), the GS 50 profile stop measuring system represents a cost effective option for glazing bead preparation.

  • Stop settings can be changed using a servo motor


Technical data:

Model:

230 V

Length:

3000 mm

Roller width:

400 mm

Operating height:

850 - 1050 mm

Weight:

180 kg

Cutting and mitre saws

PES 400

PES 400

PES 400 single-head profile saw for economical cutting of aluminium profiles.


Technical data:

Motor:

~ 400 V / 1.8 kW

Horizontal mitre range:

0°/ 90°/ 0°

Locating position:

45° / 90° / -45°

Saw blade diameter:

400 mm

Extraction nozzle diameter:

100 mm

Weight:

230 kg

215 NS

215 NS

Jack rafter saw for aluminium profiles to create vertical and horizontal mitre cuts.

  • Adjustment by means of worm gear with crank handle


Technical data:

Motor:

400 V / 3 kW

Speed:

2800 rpm

Cutting width:

450 mm (at 90°)

310 mm (at 45°)

Cutting height:

215 mm (at 90°)

150 mm (at 45°)

Horizontal mitre range:

45° (left) / 25° acute angle (right)

Vertical mitre range:

60° acute angle (left) / 30° acute angle (right)

Roller width:

400 mm

Saw blade diameter:

550 mm

Extraction nozzle diameter:

100 mm

Weight:

300 kg

200 NCS

200 NCS

Jack rafter saw for vertical and horizontal mitre cuts on aluminium profiles.

  • Motorised incline adjustment with digital display


Technical data:

Motor:

~ 400 V / 3 kW

Speed:

2800 rpm

Cutting width:

420 mm (at 90°)

300 mm (at 45°)

Cutting height:

200 mm (at 90°)

140 mm (at 45°)

Horizontal mitre range:

45° (left) / 25° acute angle (right)

Vertical mitre range:

60° acute angle (left) / 30° acute angle (right)

Saw blade diameter:

520 mm

Extraction nozzle diameter:

100 mm

Weight:

350 kg

200 NS

200 NS

Jack rafter saw for vertical and horizontal mitre cuts on aluminium profiles.

  • Adjustment by means of worm gear with crank handle


Technical data:

Motor:

400 V / 3 kW

Speed:

2800 rpm

Cutting width:

420 mm (at 90°)

300 mm (at 45°)

Cutting height:

200 mm (at 90°)

140 mm (at 45°)

Horizontal mitre range:

45° (left) / 25° acute angle (right)

Vertical mitre range vertical:

60° acute angle / 30° acute angle (right)

Saw blade diameter:

520 mm

Extraction nozzle diameter:

100 mm

Weight:

300 kg

170 NS

170 NS

Jack rafter saw with adjustment by means of worm gear with crank handle.


Technical data:

Motor:

400 V / 3 kW

Speed:

2800 rpm

Cutting width:

430 mm (at 90°)

305 mm (at 45°)

Cutting height:

170 mm (at 90°)

115 mm (at 45°)

Horizontal mitre range:

45° (left) / 25° acute angle (right)

Vertical mitre range:

60° acute angle (left) / 30° acute angle (right)

Saw blade diameter:

420 mm

Extraction nozzle diameter:

100 mm

Weight:

300 kg

PSA

PSA

Automatic profile saw, for cutting short lengths or automatic cutting of aluminium profiles.


Technical data:

Motor:

400 V / 3 kW

Speed:

2800 rpm

Length of automatic feed:

Max. 600 mm

Offcut:

Min. 90 mm

Saw blade diameter:

400 mm

Horizontal mitre range:

90°

Weight:

350 kg

BS 550

BS 550

For vertical length cutting and mitre cuts on thick-walled aluminium profiles, such as balcony profiles.


Technical data:

Motor:

400 V / 3 kW

Speed:

2800 rpm

Horizontal mitre range:

20° (on both sides)

Locating position:

45° (left) / 90° / 45° (right)

Saw blade diameter:

550 mm

Extraction nozzle diameter:

80 mm and 50 mm

Weight:

827 kg


TL 350

TL 350

With a 350 mm saw blade, for cutting aluminium and PVC-U profiles.


Technical data:

Motor:

400 V / 2 kW

Cutting speed:

3200 rpm

Saw blade diameter:

350 mm

Locating position:

-45° / 90° /+45°

Horizontal mitre range:

25° (left) / 45° (right)

Weight:

68 kg

Notching saws

PAS Compact and PAS Compact 650

PAS Compact and PAS Compact 650

For notching and cutting aluminium profiles. Double-headed saw, automatic saw blade feed and fixed profile positioning for cutting.


Technical data:

PAS Compact

PAS Compact 650

Motor:

400 V / 2 x 3 kW

400 V / 2 x 3 kW

Speed:

2800 rpm

2800 rpm

Horizontal saw blade:

+60° / -60°

+60° / -60°

Vertical saw blade:

+45° / -60°

+45° / -60°

Profile support:

+60° / -60°

+60° / -60°

Saw blade diameter:

500 / 550 mm

500 / 650 mm

Notching height:

210 mm (at 90°)

260 mm (at 90°)

Notching depth:

190 mm (at 90°)

185 mm (at 90°)

Notching width:

180 mm (at 90°)

230 mm (at 90°)

Weight:

1250 kg

1500 kg

UAS / UAS Digital

UAS / UAS Digital

For notching aluminium profiles.

  • UAS Digital: Digital display for 3 angle values


Technical data:

Motor:

400 V / 2 x 3 kW

Speed:

2800 rpm

Horizontal saw blade:

+45° / -45° (adjustable height)

Vertical saw blade:

+45° / -45°

Profile support:

+22.5° / -90°/ -22.5° (adjustable height)

Saw blade diameter:

400 / 450 mm

Notching height:

160 mm (at 90°)

Notching depth:

135 mm (at 90°)

Notching width:

250 mm (at 90°)

Weight:

540 kg

AS 450 / AS 450 Digital

AS 450 / AS 450 Digital

For notching aluminium profiles.

  • AS 450 Digital: Digital display for 3 angle values


Technical data:

Motor:

400 V / 2 x 3 kW

Speed:

2800 rpm

Horizontal saw blade:

Adjustable height

Vertical saw blade:

+45° / -45°

Profile support:

+22.5° / -90° / -22.5° (adjustable height)

Saw blade diameter:

350 / 450 mm

Notching height:

155 mm (at 90°)

Notching depth:

110 mm (at 90°)

Notching width:

250 mm (at 90°)

Weight:

400 kg

Steel saws

PDG Steel 400

PDG Steel 400

Double-headed mitre saw with 400 mm saw blade, for steel profiles, can be controlled using SchüCal.

  • 7 CNC-controlled axes:
    (movement of saw head (X axis), inclining the W and U axis, 2 x saw blade feed, 2 x speed monitoring)
  • Constant torque through brushless motor controlled by frequency converter
  • CNC-controlled saw feed
    o Adjustable feed rate
    o Adjustable cutting depth
    o Fast retraction
  • Ventilation (by moving the profile supports for protection of the saw blade that moves back after the separating cut)


Technical data:

Model:

5.0 m

Motor:

400 V / 2 x 4.5 kW

Speed:

40 – 250 rpm, continuous

Angle of incline:

Up to 45° (outwards), up to 45° (inwards)

Saw blade diameter:

400 mm

Cutting length (min.):

250 mm for double cut (90°/90°), > 250 mm with short cutting program (90°/90°))

Cutting length (max.):

5000 mm for double cut, 9600 mm for excess length cut

Weight:

2800 kg

PSU 450 H

PSU 450 H

The PSU 450 H steel saw is ideal for cutting large steel profiles and steel tubes. The PSU 450 H has an automatic, hydraulic feed. The saw blade feed and the initial cutting point can be set using a control dial.


Technical data:

Motor:

400 V / 3/3.6 kW

Speed:

12 / 24 / 48 / 96 rpm

Swivel range:

+30° / +45° / 90° / -45° / -30°

Saw blade diameter:

450 mm

Weight:

1250 kg

Please note

We reserve the right to make changes to dimensions and designs in the interest of technical progress.
Illustrations may differ from the original and/or contain options which would incur an additional charge.

Saws
Dashboard
Close
