Schüco Sun Shading System CSB in front of Schüco Façade System FWS 50/60

image cmcid:144481

Forward-mounted shading solution for façades – extremely wind-resistant

The Schüco CSB (Concealed Shaped Blind) sun shading system, externally forward-mounted on the Schüco FWS 50 and Schüco FWS 60 façade systems, offers a convenient shading solution that heavily reduces solar heat gain in buildings on sunny days.

With a high level of transparency of over 23 percent, the user retains the link to the outside world even when the blind is completely closed, including on days with extremely high winds as well. The stable louvre blades made from extruded aluminium can withstand extremely high wind loads.

The aluminium sun shading system, which can be rolled up, impresses with an attractive, timeless visual design and offers yet further design options: in order to meet the most varied architectural requirements in building planning, the louvre blade blind is available in six anodised colours, C0 and C31 to C35, guaranteeing perfect integration into the façade appearance.

Awards & Certifications

Awards & Certifications

Awards & Certifications

Planning benefit

  • Façade-integrated guide tracks with face-mounted box in front of the façade
  • Extremely high wind stability
  • Complete shading of direct solar radiation when the angle of the sun is 21° or higher
  • Detection of obstacles when blinds are raised
  • Surface finish that is resistant to weathering thanks to anodised finish
  • Narrow and modern louvre blade design

Gallery

Technical information

Min.-max. height
1000...4000 mm
Min.-max. width
600...2400 mm
Max. area
8 m²
Power supply
230 V/50 Hz
Profile dimensions
5 x 38.6 mm
Installation option
Façade-mounted
Wind stability
25 m/s
Louvre blade angle
Fixed
Louvre blade type
Micro louvre blade
Properties
Sun shading, Protection from heat, Screening
Surface finishes
Anodised
Max. width
2400 mm
Min. width
600 mm
Max. height
4000 mm
Min. height
1000 mm
Area of application
External use, Residential projects, Commercial projects, Façades
Louvre blade arrangement
Horizontal
Material
Aluminium
Operating type
electric
Control unit
KNX
Automatic
Yes
Timer automation system
Yes
Weather-resistant
Yes
Power consumption
100-260 VA
Integrated thermal protection
Yes
CE marking
Yes
Low-maintenance
Yes
