Schüco Panorama Design Sliding System AS PD 75.HI Performance Line
HOW DOES THIS BENEFIT YOU?
The key features of Schüco AS PD 75.HI
Can a Panorama Design sliding door be frameless and barrier-free at the same time?
Yes, it can - with the right technology.
Have you got 3 minutes? Take a look now and get to know the Schüco AS PD 75.HI Panorama Design sliding system.
Schüco AS PD 75.HI - Offers individuality without complexity
The Schüco Panorama Design sliding door AS PD 75.HI brings together the features of multifunctionality and style in various product lines, without sacrificing their individuality. The technical performance features of all the lines are all at the highest level. Additional features such as the integration of sun shading mean that there is a wide choice of configurations for the Panorama Design sliding door. In addition to the standard opening types, the sliding units can be configured as desired and tailored to the requirements of the particular façade design.
Planning benefit
- Level threshold for high user comfort.
- Dynamic cover profile in the outer frame for a flush appearance even when the unit is open.
- Free vent configuration for maximum planning flexibility.
- Reduced frame view through concealed side and top vent frame.
- Optional timber-aluminium design in the interlock section for increased comfort.
- Optional monitoring of opening and closing for additional security.
- The Access Line is also available as a TipTronic option on request and can be mechatronically operated.
- Can be combined with Schüco AB ZDS sun shading.
Gallery
Technical information
- Min. vent height
- 1000 mm
- Max. vent height
- 3500 mm
- Min.-max. vent height
- 1000...3500 mm
- Min. vent width
- 1000 mm
- Max. vent width
- 3500 mm
- Min.-max. vent width
- 1000...3500 mm
- Vent frame face width
- 0 mm
- Min. face width of interlocking section
- 35 mm
- Min. system basic depth
- 218 mm
- Min.-max. system basic depth
- 218...218 mm
- Uw value of window (≥)
- 0.82 W/(m²·K)
- Watertightness
- E 1050
- Burglar resistance
- Up to RC3
- Operating type
- electric
- Max. vent weight
- 600 kg
- Min. face width
- 35 mm
- Max. glass/panel thickness
- 60 mm
- Total basic depth
- 218 mm
- Width of vent frame
- 75 mm
- Max. unit width
- 19800 mm
- Max. unit height
- 3500 mm
- Outer frame face width
- 0 mm
- Min. face width of mullion
- 0 mm
- Min.-max. face width of mullion
- 0...0 mm
- Min. face width of meeting stile
- 35 mm
- Min.-max. face width of meeting stile
- 35...35 mm
- Min.-max. glass/panel thickness
- 40...60 mm
- Threshold height
- 0 mm
- Area of application
- Internal use, External use, Residential projects, Commercial projects, Doors, Façades, Healthcare, Education, Accommodation facilities
- Meeting stile design
- Yes
- Number of vents
- 4
- Fixed lights/identified vents
- Yes
- Number of tracks
- Double track
- Track material
- Aluminium
- Roller carriage material
- Aluminium
- Surface finishes
- RAL, Powder, Anodised, Paint
- Concealed lock
- Yes
- Concealed drive system
- Yes
- TipTronic
- Yes
- Electronic drive
- Yes
- Opening type
- Type 2A, Type 2A/1, Type 2B, Type 2C, Type 2E, Type 2G/1, Type 2G
- Air permeability
- Class 4
- Wind load resistance
- Class C4
- Drainage levels
- 4
- Schüco sun shading possible
- Yes
- Electronic monitoring
- Yes
- CE marking
- Yes
- Cradle2Cradle
- Yes
