Schüco CC 800

Four in one go - faster than ever.

Our latest solution for the efficient fabrication and assembly of Schüco windows, doors and façades - the fully automatic four-head corner crimper machine including automatic infeed and outfeed. Manually pre-assembled frames are punched and transported out with a precision fit and high-quality uniformity.

Transformation
Transformation
Individual advice
Individual advice
Industry 4.0
Industry 4.0
Robotic technology
Robotic technology
Sustainable concepts
Sustainable concepts
The right machine for everyone

The machine creates a fully automatic punching process for a wide variety of profile geometries. In addition, the CC 800 guarantees a high process speed and punches a frame every 70 seconds.

Corner connection in the run

The CC 800 lays the foundation for automated assembly and thus secures the future of the workshop. It punches a frame every 70 seconds, whether large or small. CC 800 - the new standard in frame assembly.

Flexible and fully automatic

A fully automatic compensation of profile tolerances is integrated in the functions of the CC 800. In addition, the CC 800 can be used flexibly in different workshop layouts, whether windows, doors or facade elements - and is particularly suitable for line production.

"The CC 800 is our answer to the shortage of skilled workers. The latest four-head corner connector machine punches a frame every 70 seconds. Twice as many frames in less time than any conventional way of working. Even large facade or sliding elements no longer have to be nailed, but nailed easily punched with the CC 800. This makes it the heart of every almost industrial line production in your assembly."

Alexander von Bobart, Head of Customer Development, Schüco International KG

Technical data CC 800

  • Easy control from SchüCal

  • Simple processing of profiles with level offset without the use of special knives

  • Different punching modes: 4-fold or 2x2 punching possible

  • 4-fold punching - Smallest frame: 580x480mm

  • 2+2 punching - Smallest frame: 380x420 mm

  • Largest frame:  4000x6500 mm

  • Punching heights of up to 250mm profile height possible

FAQ about the new CC 800

When will the CC 800 be available?

When will the CC 800 be available?

Sales of the new Schüco CC 800 will start at the BAU trade fair in 2023. Are you interested in viewing the machine? Then get in touch with your Schüco contact person to arrange a viewing and consultation appointment.

The CC 800 is very flexible in structure and design. What are the steps for a successful installation?

The CC 800 is very flexible in structure and design. What are the steps for a successful installation?

Our CC 800 can be used very flexibly and adapts optimally to your production needs - whether in assembly line production or as a self-sufficient corner connector machine. Together with our workshop planning experts, we will find the ideal equipment and size for you.

How much space does the CC 800 need?

How much space does the CC 800 need?

The space requirements of our CC 800 can be variably adapted to your production hall. For example, the CC 800 needs a space of 17.7m x 6.5m (LxW) for a machine set up for the assembly of windows. This allows frames with a size of 2.8m x 2.5m to be manufactured. In this example, the automatic transport in and out is included.

Which production volume is the machine suitable for?

Which production volume is the machine suitable for?

Due to the flexible equipment options of the CC 800, we would be happy to advise you personally and individually. The machine has the capacity to punch a frame every 70 seconds, including dimensional positioning. All in all, the CC 800 offers incredible advantages in terms of stability and the increase in quality of your processes. These advantages are guaranteed by a tolerance distribution of the 4 corners and a computer control via barcode for setting the machine to the correct visual dimensions and positioning of the punching knives. In addition, almost all profiles can be punched with the same punching knives and special knives are no longer necessary.
