Door and wall construction for multi-functional fire and smoke-protection applications

The proven Schüco ADS 80 FR 30 (Fire-Resistant) door system with a basic depth of 80 mm, which is based on highly stable 5-chamber hollow profiles, features impressive versatility in terms of application, function and design.

For additional requirements in building security and automation, the highly stable aluminium systems for fire and smoke-protection applications can be upgraded to multi-functional doors.

Passive house-certified mullion/transom façade for a variety of solutions

Based on pioneering isolator technology, the Schüco FWS 50.SI (Super Insulated) façade system offers highly thermally insulated solutions for designing diverse façades and skylights to passive house level, including optimised fabrication and installation processes.

With its high flexibility and broad system range, the system ensures mullion/transom constructions for the most varied functional and design requirements in high-end residential and commercial projects.

A transparent system solution integrated in the profile for spandrel safety barriers blends in seamlessly and elegantly into the external façade appearance.

Aluminium fire-resistant construction with 90-minute fire resistance for maximum flexibility

Added security: The Schüco FireStop ADS 90 FR 90 aluminium fire protection system is part of the innovative Schüco FireStop system platform and offers a comprehensive fire door and wall range with 90 minutes of fire resistance – tested in accordance with EN 1634 / EN 1364 and DIN 4102.

Uniquely elegant, thermally broken fire-resistant constructions are possible thanks to maximum flexibility with planning and design.

100% testado e certificado, o sistema Schüco FWS 50 possibilita uma construção segura e eficiente de fachadas com design variados. A sua compatibilidade com muitos outros sistemas Schüco, inclusive com sistemas de proteção solar fixos e móveis, fazem do FWS 50 um dos produtos mais completos.

Universal use as heavily used commercial door and stylish entrance door

Excellent insulation properties combined with high stability – the Schüco AD UP 75 door system with a 75 mm basic depth offers high functional reliability for all requirements in luxury residential and commercial buildings.

With its groundbreaking construction principle and modular gasket system, the system sets new standards in thermal insulation, weathertightness, load-bearing capacity and durability for aluminium door systems.

Excellent design combined with proven fire protection for 30 minutes of fire resistance

The Schüco FireStop ADS 90 FR 30 fire door is part of the Schüco FireStop system platform and offers an attractive fire door and wall range, tested in accordance with EN 1634/EN 1364 and DIN 4102 for 30 minutes of fire resistance.

The thermally broken fire-resistant construction with a basic depth of 90 mm is distinguished by its unique elegance: extremely narrow profile face widths allow for the greatest possible transparency, while integrated closers and concealed door hinges impress with their minimalist design.
